Format Parameter Settings

6-76
Chapter 6: Programming
These commands affect the type of test signal pro-
duced by the ISA generator. The commands also
determine the timing of the signal. All the param-
eters set by these commands can be saved as a single
Format in the generator's on-board Format storage
locations.
ASCT Analog Sync Composite Type
ASSG Analog Sync Signal Gate
ASSS Analog Sync Signal Swing
AVCM Analog Video Calibration Method
AVCO Analog Video Color Order
AVCS Analog Video Color Subcarrier
AVPG Analog Video Pedestal Gate
AVPS Analog Video Pedestal Swing
AVSS Analog Video Signal Swing
AVST Analog Video Signal Type
CSPG Composite Sync Pulse Gate
CSPP Composite Sync Pulse Polarity
DCBM Display Code Bit Mask
DCEX Display Code EXpected
DSCT Digital Sync Composite Type
DSST Digital Sync Separate Type
DVSP Digital Video Signal Polarity
DVST Digital Video Signal Type
EQUA EQUalization interval After vertical sync
pulse
EQUB EQUalization interval Before vertical sync
pulse
GAMA GAMmA correction factor
GAMC GAMma Correction
HRAT Horizontal RATe
HRES Horizontal RESolution (active pixels per
line)
HSIZ Horizontal SIZe
Model 801GC, 801GF & 801GX¥Rev. A
