Model 801GC, 801GF and 801GX Specifications

Signal Formats

Over 100 built-in formats
All models share a common library of
built-in formats. Not all formats may work
on all models of generators. See chapter 4
for more information.
TV encoded color video (801GX only):
NTSC: 5
PAL: 5
HDTV analog video:
European: 3
Japanese: 3
Computer analog video:
PAL: 3
RS-170: 3
Barco: 6
HP: 7
IBM: 16
Intergraph: 4
Mac: 13
NEC-PC: 2
Sony: 3
Sun: 10
VESA: 33
Computer digital video (801GC & 801GX only):
AT&T: 3
IBM: 7

Custom Formats

Storage capacity: 300 + built-in formats
Edit method: screen editor on UUT or via
commands over computer ports
Custom Sequences
Storage capacity: total steps 2133 - # of sequences
Edit method: Screen editor on UUT or via
commands over computer ports
Parameters:
Select Format
Select Image & version
Auto step delay: 0.1 Sec. to 24 Hr.
Sequence name: 8 characters
A-2
Appendix A: Specifications

Test Images

Over 100 built-in imagess
All models share a common library of
built-in images. Not all images may work
on all models of generators. See chapter 5
for more information.
Partial Listing:
Format Format spreadsheet
ColorBar Color bars, up to 16 bars
GrayBar Gray bars, up to 16 bars
Raster Active pixels set to black
BrightBox Five light meter boxes
Dot_10 Hatch/dots, small
Dot_12 Hatch/dots, medium
Dot_24 Hatch/dots, large
Hatch_10 Crosshatch, 10 boxes
Hatch_12 Crosshatch, 12 boxes
Hatch_24 Crosshatch, 24 boxes
Grill_44 Vertical stripes, 4 pixels
Grill_44(I) Horiz stripes, 4 pixels
Grill_33 Vertical stripes, 3 pixels
Grill_33(I) Horiz stripes, 3 pixels
Grill_22 Vertical stripes, 2 pixels
Grill_22(I) Horiz stripes, 2 pixels
Grill_11 Vertical stripes, 1 pixel
Grill_11(I) Horiz stripes, 1 pixel
Linearity Xhatch with tics, circles
SMPTE133 Medical test image
Focus_Cx Full screen "C" w/ "x"
Focus_H Full screen of "H"
Focus_Oo Full screen of "O" and "o"
Text_9 Random small text
Text_16 Random larger text
Cubes Animated rotating cubes
Persist 17 moving boxes
Flat All active pixels white
Outline White border around active area
SMPTEBar TV vectorscope
Stairs20 TV 20% gray levels
PulseBar TV waveshape
Burst_100 TV 100% multiburst
MEME Full screen of ÒMEÓ for focus
Custom Images
Storage capacity: Total # of primitives
# of images
Edit method: Screen editor on UUT or via
commands over computer ports
Edit functions: exit, draw, insert, delete, move, cur
sor, save, change
Primitives: dot, line, rectangle, oval, triangle,
characters, text string, format data,
grid, croshattches, H-grill, V-grill,
centermark, limits
Colors: Up to 15 colors (+black) from a
palette of 63 colors and grays
Model 801GC, 801GF & 801GX ¥ Rev. A
2048 -
