Descriptions of the Images

Acer1

Description

Acer2

Description

Acer3, Acer4, Acer5 and Acer6

Description

Acer7 and Acer 8

Description

Acer9

Description
4-4
Chapter 4: Built-In Images
Special test image specified by some display
manufacturers. Consists of two sets of color bars
and five blocks of "#" characters on a white crosshatch
witha black background.
Special test image specified by some display
manufacturers. Consists of colorbars, lines of "#"
characters and a green border.
Special test images specified by some display
manufacturers. Consists of a large and small white
circles centered on either a yellow (Acer3), magenta
(Acer4), cyan (Acer5) or white (Acer6) crosshatch
on a black background.
Special test image specified by some display
manufacturers. Consists of five blocks of either white
"#" (Acer7) or "H" (Acer8) characters on a black
background.
Special test image specified by some display
manufacturers. Consists of mostly a white field with
two rows of color bars at the bottom.
