Quantum Data 801GC, 801GF, 801GX Owner's And Programmer's Manual page 152

Table 4-1
Available drawing
primitives in a
Custom Image
Table 4-2
Available colors in a
Custom Image
6-26
Chapter 6: Programming
Primitive Name Parameters
Rectangle color, width, height, left, top, fill patn
Oval color, width, height, left, top, fill patn
Line color, x1, y1, x2, y2
Dot color, x, y
Grid color, # of xboxes, # of yboxes
H-Grill color, line width
V-Grill color, line width
Characters color, character #, font#
Limits color
CenterMark color
Triangle color, x1, y1, x2, y2, x3, y3, fill patn
Format color, left x, top y
Hatch_I-O color, # of xboxes, # of yboxes
Hatch_O-I color, # of xboxes, # of yboxes
Cross color
Text color, x, y, font#, text string
Seq. Step color, x, y
Available Colors:
and grays as being available. However, the 801G*
can only work with 16 colors at a time. One of the
colors must be black. Attempting to use more than
16 colors may cause parts of the image to draw
with the wrong color. A number in the color name
refers to its % intensity level. The current firmware
does not support editing the colors or gray levels
Black Cyan50
Red Brown
Green Gray3
Yellow Gray5
Blue Gray7
Magenta Gray10
Cyan Gray13
White Gray17
Red50 Gray20
Green50 Gray23
Yellow50 Gray25
Blue50 Gray27
Magenta50 Gray30
Model 801GC, 801GF & 801GX¥Rev. A
The color list shows 63 colors
Gray33 Gray70
Gray37 Gray73
Gray40 Gray75
Gray43 Gray77
Gray47 Gray80
Gray48 Gray83
Gray50 Gray87
Gray51 Gray90
Gray53 Gray93
Gray57 Gray95
Gray60 Gray97
Gray63 Red75
Gray67 Green75
Yellow75
Blue75
Magenta75
Cyan75
HueI
HueQ
HueNegI
HueNegQ
Foreground
Background
Clear
