Additional Model 801GF Specifications

Pixel Timing
Frequency Range: 3.9975 MHz to 250 MHz
Step: 0.035 Hz
Jitter: 800 pS line-to-line (1 sigma)
Accuracy: 25 ppm
Horizontal Timing
Frequency Range: 1.00 Ð 130KHz
Total pixels per line:
Range: 144 to 65,535 pixels
Step: 1 pixel
Active pixels per line:
Range: 16 to 2048
(up to 32,768 pixels under special
conditions)
Step: 1 pixel
Sync pulse width:
Range: 1 to Htot - Hact -HSdel pixels
Step: 1 pixel
Sync delay (front porch):
Range: 1 to Htot - Hact -HSwid pixels
Step: 1 pixel
Vertical Timing
Frequency Range: 1 to 650Hz
Vertical total scan lines per frame:
Range: 2 to 4096 lines (progressive)
5 to 8191 lines (interlace)
Step: 1 line (progressive)
2 lines (interlace)
Vertical active scan lines / frame:
Range: 1 to 2048 lines (progressive)
2 to 2048 lines (interlace)
(up to 4096 lines under special
conditions)
Step: 1 line (progressive)
2 lines (interlace)
Vertical Sync pulse width:
Range: 1 to Vtot - Vact -VSdel lines
Step: 1 line
Modes:American or European
Vertcal Sync delay (front porch):
Range: 0 to Vtot - Vact -VSwid lines
Step: 1 line
Horizontal actives beyond 2048
pixels require a reduced vertical
active limit. Vertical actives
beyond 2048 lines require a
reduced horizontal active limit.
Required limit reductions shown
in table. Horizontal actives
beyond 4096 pixels repeat the
information contained in the first
4096 pixels of each scan line.
Digital Sync
Modes:
Eq. Pulse Width: HSwidth / 2 pixels
Serr. Pulse Width: Htot - HSwid pixels (progressive)
Equalization Interval:
pixels typical
Step:
Interval Modes:
Outputs
RGB ANALOG VIDEO OUTPUTS
Source Z:
Config:
Output levels:
Output protection: Output buffer / 75
V Active Rise / Fall:
H Active pixels
lines
Overshoot:
513-1024 4096
1025-2048 2048
DIGITAL OUTPUTS
2049-4096 1024
Source Z:
4097-8192 512
Levels:
8193-16384 256
16385-32768 128
Rise / Fall : < 4.0 nSec
Separate Horiz. & Vert.
Composite
Composite Configurations:
American HS OR'ed with VS
American Serrated
American Serr. &Eq.(interlaced only)
European HS OR'ed with VS
European Serrated
European Serr. & Eq.(interlaced only)
[Htot/2] - HSwid pxls (interlace)
Before: 0 to Vtot - Vact -VSwid - EqAfter Lines
After: 0 to Vtot - Vact -VSwid - EqBefore Lines
1 line
American (interval is equal to programmed value)
European (interval =1/2 line < programmed value)
75-ohms
R, G, B or Y, Pr, Pb
Video Swing: 0 to +1.0 V
Sync Swing: 0 to Ð 400 mV
Setup: 0 to 100 IRE
Autocal: autoadjust (internal precision ref.)
1.5 nSec. (typical)
10% (all outputs terminated)
75-ohms 2%
Ô0Õ = 0 VÔ1Õ = 5 V open circuit
Ô0Õ = 0 VÔ1Õ = 2.5 V (term)
Appendix A: Specifications
series term
A-5
