Technical information
1
2
3
4

A.3.2 LAN connector

The LAN connector installed in the device is an M12 8P X-Code female connector.
PIN
1
2
3
4
5
6
7
8
A.3.3 WWAN connectors
The WWAN connector installed is an N female coaxial.
PIN
Internal
External
A.3.4 WLAN connectors
The WWAN connector installed (for devices equipped with this interface) is an N female coaxial.
PIN
22
+ V DC
+ V DC
0 V
0 V
GE Signal -> Signal
BI-DA+-> Tx+ (1)
BI-DA--> Tx- (2)
BI-DB+-> Rx+ (3)
BI-DB- -> Rx- (6)
BI-DD+(4)
BI-DD-(5)
BI-DC- (7)
BI-DC+(8)
Signal
RF In/Out
Gnd
Signal
M12 8P X-Code female connector
N-Type connector (female jack)
N-Type connector (female jack)
Teldat S.A.
Teldat H2 RAIL
