Radio information
Band 1
Band 8

B.2 WI-FI specifications

The Wi-Fi radio communications are provided by the WPEA-252NI module in compliance with 802.11a/b/g/n stand-
ards.
Frequency Range
Number of Channel
Operating Frequency
Output Power.
(tolerance ± 2 dB)
28
Tx: 1920–1980 MHz
Rx: 2110–2170 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
a/n ISM Band: 5.150 ~ 5.725 GHz.
b/g/n ISM Band: 2.400 ~ 2.4835 GHz.
2.4 GHz:
802.11b, 802.11g, 802.11n (20MHz): 13.
802.11n (40MHz): 9.
5.0 GHz:
5.18 ~ 5.32 GHz.
802.11a, 802.11n (20MHz): 8.
802.11n (40MHz): 4.
5.50 ~ 5.70 GHz
802.11a, 802.11n (20MHz): 8.
802.11n (40MHz): 3.
2.4 GHz:
b/g/n ISM Band: 2412 MHz - 2484 MHz.
5.0 GHz:
a/n ISM Band: 5150-5350 MHz, 5470-5725 MHz.
Note: The maximum RF power setting will vary according to individual country
regulations.
802.11a: +14dBm @54Mbps.
802.11b: +19dBm @11Mbps.
802.11g: +16dBm @54Mbps.
802.11gn HT20: +15dBm @MCS7.
802.11gn HT40: +14dBm @MCS7.
802.11an HT20: +12dBm @MCS7.
802.11an HT40: +11dBm @MCS7.
+23 dBm ± 1 dB
+23 dBm ± 1 dB
