Technical information
SPEED
CONNECTOR
ANTENNA
Wireless LAN interface
Wireless LAN (radio 1/2)
WLAN standards
Frequency bands 2.4 GHz in-
door/outdoor (EU)
Frequency bands 5 GHz indoor
(EU)
Frequency bands 5 GHz out-
door (EU)
WLAN modes
Automatic Rate Selection (ARS) Available.
Transmission rate
Data rates
Data rates for 802.11n, Long
Guard (800ns), 20 MHz
Data rates for 802.11n, Short
Guard (400ns), 20 MHz
Data rates for 802.11n, Long
Guard (800ns), 40 MHz
Data rates for 802.11n, Short
Guard (400ns), 40 MHz
Receive Sensitivity
(1R)
24
Depends on the WWAN version in the device. Please see the user manual for the
module in question.
Up to eight type N coaxial connectors.
The antennas are supplied separately from the device.
802.11n (Mimo 2x2); 802.11b; 802.11g; 802.11a; 802.11h.
2.4 GHz Indoor/Outdoor (2412-2484 MHz) max. 100 mW EiRP.
5 GHz indoor (5150-5350 MHz) max. 200 mW EiRP allowed.
5 GHz outdoor (5470-5725 MHz).
2,4 GHz Operation: 802.11b only; 802.11g only, 802.11b/g/n mixed; 802.11b/g/n
mixed long;802.11b/g/b mixed short; 802.11b/g/n ; 802.11g/n; 802.11n only 5 GHz
Operation: 821.1a only;802.11a/n; 802.11n only.
Automatic.
802.11a: 6~54 Mbps / 802.11b: 1~11 Mbps.
802.11g: 6~54 Mbps / 802.11n (HT20): MCS0 ~ MCS15 / 802.11n (HT40): MCS0
~ MCS15.
MSC0 6,5 Mbps; MSC1 13 Mbps; MCS2 19,5 Mbps; MCS3 26 Mbps; MCS4 39
Mbps; MSC5 52 Mbps; MCS6 58,5 Mbps; MCS7 65 Mbps; MCS8 13 Mbps; MCS9
26 Mbps; MCS10 39 Mbps; MCS11 52 Mbps;MCS12 78 Mbps; MCS13 104 Mbps;
MCS14 117 Mbps; MCS15 130 Mbps.
MSC0 7,2 Mbps; MSC1 14,4 Mbps; MCS2 21,7 Mbps; MCS3 28,9 Mbps; MCS4
43,3 Mbps; MSC5 57,8 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27
Mbps; MCS9 54 Mbps; MCS10 81 Mbps; MCS11108 Mbps; MCS12 162 Mbps;
MCS13 216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
MSC0 13,5 Mbps; MSC1 27 Mbps; MCS2 40,5 Mbps; MCS3 54 Mbps; MCS4 81
Mbps; MSC5 108 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27 Mbps;
MCS9 54 Mbps; MCS10 81 Mbps; MCS11108 Mbps; MCS12 162 Mbps; MCS13
216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
MSC0 15 Mbps; MSC1 30 Mbps; MCS2 45 Mbps; MCS3 60 Mbps; MCS4 90
Mbps; MSC5 120 Mbps; MCS6 135 Mbps; MCS7 150 Mbps; MCS8 30 Mbps;
MCS9 60 Mbps; MCS10 90 Mbps; MCS11 120Mbps; MCS12 180 Mbps; MCS13
240 Mbps; MCS14 270 Mbps; MCS15 300 Mbps.
802.11 a: < -77dBm@54Mbps.
802.11b: <-85dBm@11Mbps.
802.11g: < -77dBm@54Mbps.
