- Page 1 Manual Teldat S.A. Teldat H2 RAIL Lite Installation Manual Copyright© Teldat-DM686-I Version 1.1 05/2016 Teldat S.A. Teldat H2 RAIL Lite...
- Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
-
Page 3: Table Of Contents
Maintenance ........Teldat H2 RAIL Lite... - Page 4 WIFI Specifications ........Teldat H2 RAIL Lite...
-
Page 5: I Important Information
Note Please note that when the device operates for prolonged periods of time under extreme conditions (including high temperature and humidity) the service life of the device falls significantly. Teldat H2 RAIL Lite... -
Page 6: Chapter 1 Description
1.1 Introduction The Teldat H2 RAIL Lite router is an IP router conceived to work in hostile and extreme environments and designed to be installed in rolling stock. Thanks to its ruggedized mechanics and special characteristics, which allow it to bear extreme temperatures, this router is particularly suited for: rolling stock, automotive applications, industrial environ- ments, industrial telecontrol, distribution installations for electricity, gas, water, etc. -
Page 7: Chapter 2 Installation
Connect the power supply cable to the power supply. 2.1.1 Connecting the power The Teldat H2 RAIL Lite router family is powered by an 110 V nominal DC power source. This device has no on/off switch or fuse. To comply with electrical safety regulations, this equipment must be connected to the vehicle power network through a 1 amp approved thermo-magnetic circuit breaker (ABB-S281-UC-K-1 or equivalent). -
Page 8: Data Connection
The Teldat H2 RAIL Lite router has the following available data connectors: 2.1.2.1 LAN SWITCH The Teldat H2 RAIL Lite router incorporates a 4 port Switch, 10/100BaseT with automatic MDI/MDIX to connect to a local area network (LAN). This device has a LINK LED that indicates the state of the connection. -
Page 9: Connecting To A Wwan Antenna
2.1.2.2 AUX The Teldat H2 RAIL Lite router family has a DB9 female connector on the front panel labeled AUX. This can be used as a configuration port for the router or as a V.24 asynchronous serial port by means of a configuration com- mand. - Page 10 The following recommendations are applicable to all wireless devices: • Do not touch or move the antenna while the device is transmitting or receiving. • When the antenna is transmitting, do not touch any equipment that contains devices that radiate very close to, or Teldat H2 RAIL Lite...
-
Page 11: Connecting The Wlan Antenna
2.1.6.1 Configuring through the local console (AUX connector) The Teldat H2 RAIL Lite router has a DB9 female connector on the front panel known as “ AUX.” , which provides ac- cess to the device’s local console or may operate as an asynchronous serial port. The behavior or functionality of this interface must be previously configured. - Page 12 [192.168.1.2, 192.168.1.254] and mask 255.255.255.0. E.g. 192.168.1.2, 255.255.255.0. • Connect the IP terminal’s Ethernet interface to any of the Ethernet Switch ports on the Teldat H2 RAIL Lite router (the LAN1..4 connectors) through an appropriate Ethernet cable (M12 to RJ45).
-
Page 13: Installing The Sim Card
CD or through the WEB page. 2.2 Installing the SIM card The Teldat H2 RAIL Lite has one or two Wireless WAN interfaces. For them to operate, you may have to insert at least one SIM card in the device. -
Page 14: Installing The Sim
(1) Push the fastening toward the OPEN arrow. (2) Open the upper part of the tray. (3) Insert the SIM card so it's flush with the edges of the tray. (4) Return the tray to its original position. Teldat H2 RAIL Lite... -
Page 15: Closing The Device
(2) Refit the lid, first sliding it horizontally and then vertically so as not to ‘drag’ it over the pad. (3) Replace the seven screws holding the cover. Example of a Thermal Pad assembled over the WWAN MD1. This must be assembled in both. Fig. 12: Teldat H2 RAIL Lite... -
Page 16: Chapter 3 Meaning Of The Leds
3 Meaning of the LEDs Teldat S.A. Chapter 3 Meaning of the LEDs The following figure shows the positions of the LEDs on the front panel of the device: Teldat H2 RAIL Lite Fig. 13: : Front panel Wireless WAN interface channel 0 (cellular10/1). -
Page 17: Chapter 4 Microswitches
This block of micro-switches can be found inside Teldat H2 RAIL Lite routers. You need to remove the top casing in order to handle them, following the instructions set forth in section Installing the SIM on page 10. - Page 18 On reaching this point, you can set micro-switch ‘5’ in the OFF position (you don’t have to power off the device). This way, the saved configuration will run next time you restart the device. Also, bear in mind that the device configuration is ignored on start up but it is not deleted. Teldat H2 RAIL Lite...
-
Page 19: Chapter 5 Compliance
5 Compliance Teldat S.A. Chapter 5 Compliance 5.1 Manufacturer information Brand Teldat Manufacturer Teldat S.A. Country Spain Postal Address Isaac Newton 10, Parque Tecnologico de Madrid,28760 Tres Cantos, Madrid, Spain International Phone +34 91 807 65 65 Teldat H2 RAIL Lite... -
Page 20: Safety Warnings
1 amperio (ABB-S281-UC-K-1 o equivalente). This device is compatible with 1.8 V and 3 V SIM cards. Do not install SIM cards that do not support these voltages. Teldat H2 RAIL Lite... -
Page 21: Weee Information
0.1 % weight by weight (w/w).This declaration will be updated whenever any changes occur or other chemical substances are added to the REACH Candidate List. Information is currently provided to consumers upon request. Teldat H2 RAIL Lite... -
Page 22: Ec Declaration Of Conformity
In accordance with Article 10 of 2014/53/EU, we inform you that national restrictions and requirements may apply when it comes to authorization. These can evolve with time. Teldat S.A. recommends that you check with local au- thorities what the latest status of national regulation is. -
Page 23: Operating Frequency
5 Compliance Teldat S.A. 5.8 Operating frequency To find out more about the device's operating frequencies, see appendix RF LTE specifications on page 25 andWIFI Specifications on page 26. Teldat H2 RAIL Lite... -
Page 24: Appendix A Technical Information
Check that the SIM tray configuration is correct. A.2 Maintenance The Teldat H2 RAIL Lite routers are designed to be highly available and durable. Therefore, they do not have any moving parts. This design makes any maintenance unnecessary. A.2.1 Upgrading the software The Teldat H2 RAIL Lite router family can be upgraded to new software releases. -
Page 25: Lan Connector
N-Type Connector (Jack Female) Internal RF In/Out External A.3.4 WLAN Connectors The WWAN connector type installed is N female coaxial in those devices equipped with this interface. Signal N-Type Connector (Jack Female) Internal RF In/Out External Teldat H2 RAIL Lite... -
Page 26: Gps Connector
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE … Depending on the wireless WAN version running in the device. SPEED Depending on the wireless WAN version running in the device. Please refer to the manual on the relevant module. CONNECTOR Up to 4 coaxial connectors, type N Teldat H2 RAIL Lite... - Page 27 DB9 female located on the front panel of the device. Power INPUT VOLTAGE +110 V DC INPUT CURRENT 150 mA @110 V DC MAXIMUM POWER 15 W Dimensions and Weight TYPE Ruggedized casing for 19” rack Teldat H2 RAIL Lite...
- Page 28 WEIGHT 3.8 kg Environmental Specifications AMBIENT TEMPERATURE ON: -25 °C to 70 °C In storage: -30 °C to 85 °C RELATIVE HUMIDITY Annual average < 75 % During 30 consecutive days per year < 95 % Teldat H2 RAIL Lite...
-
Page 29: Appendix B Radio Information
Band 8 Tx: 880–915 MHz +23 dBm ± 1 dB Rx: 925–960 MHz Technology: GSM / GPRS / EDGE Bands Frequencies Conducted Transmit Power GSM 850 (850 MHz) Tx: 824–849 MHz +32 dBm ± 1 dB Teldat H2 RAIL Lite... -
Page 30: Wifi Specifications
• Europe Countries: 13 channels • Japan: 14 channels 802.11g/n: • USA: 11 channels • Europe Countries: 13 channels • Japan: 13 channels Output Power. Note: The maximum RF power setting will vary according to specified country regulations . Teldat H2 RAIL Lite... - Page 31 • +15dBm at MCS0/8 , 1/9 , 2/10 , 3/11 , 4/12 , 5/13, MCS6/14 • +12dBm at MCS7/15 5.725~5.825 GHz Band • +14dBm at MCS0/8 , 1/9 , 2/10 , 3/11 , 4/12 , 5/13 • +12dBm at MCS6/14 • +10dBm at MCS7/15 HT40 5.150~5.350 GHz Band Teldat H2 RAIL Lite...
- Page 32 • +13~15dBm at MCS0/8 , 1/9 , 2/10 , 3/11 , 4/12 , 5/13, MCS6/14 • +10~12dBm at MCS7/15 5.725~5.825 GHz Band • +12~15dBm at MCS0/8 , 1/9 , 2/10 , 3/11 , 4/12 , 5/13, MCS6/14 • +10~12dBm at MCS7/15 Teldat H2 RAIL Lite...
