Output power limitation (without
antenna gain)
Output Power
(1T)
Bandwidth (802.11n)
GPS Interface
STANDARDS
SATELLITE CHANNELS
CONNECTOR
ANTENNA
Configuration interface
INTERFACES
PROTOCOLS
SPEED
CONNECTOR
Power
INPUT VOLTAGE
Teldat H2 RAIL
802.11gn HT20: < -74dBm@MCS7 / 802.11gn HT40: < -71 dBm@MCS7.
802.11an HT20: < -73dBm@MCS7 / 802.11an HT40: < -70dBm@MCS7.
Adjustable in the following steps: 5, 8,11,14,16 dBm and maximum. Maximal
power varies depending on data rate, frequency band and country setting.
802.11 a: 1 4dBm ± 2dBm@54Mbps.
802.11b: 1 9dBm ± 2dBm@11Mbps.
802.11g: 16dBm ± 2dBm@54Mbps.
802.11gn HT20: 15dBm ± 2dBm@MCS7 / 802.11gn HT40: 14dBm ±
2dBm@MCS7.
802.11an HT20: 12dBm ± 2dBm@MCS7 / 802.11an HT40: 11 dBm ±
2dBm@MCS.
20/40 MHz (bundling two adjoining 20 MHz channels into one 40 MHz channel).
NMEA.
Maximum 30 channels (16 GPS, 14 GLONASS) simultaneous tracking.
RF FME male.
3.3 V Active.
Passive.
This can be configured in two modes:
Asynchronous Port :
V24 DCE. Hardware flow control is not permitted.
Local Console:
V.24 DCE only 8-N-1, without flow control.
Asynchronous Port:
AT, PPP, GPS-DATA.
Asynchronous Port:
300 at 115,200 bps.
Local console:
9,600 bps (configurable up to 115,200).
DB9 female located on the front panel of the device.
Depending on the model:
+110 VDC.
Technical information
