3 Components and power supply
Note
The equipment is intended to be both handled and installed by qualified service personnel. If not, the
device may be damaged and malfunction.
There are two brackets, with slots attached to the front panel, to hold the device firmly in place.
3.2.1 Assembly: Recommendations
Insert the router into a 19-inch rack and align the brackets in the rack.
We recommend securing the unit to the rack using the screws and nuts provided. This will ensure the device is se-
curely mounted.
Fig. 5: Mounting screws
3.2.2 Outline drawing
The following outline drawing provides installation instructions:
6
Teldat S.A.
Teldat H2 RAIL
