- Page 1 Manual Teldat S.A. Teldat H1 RAIL Installation Manual Copyright© Teldat-DM496-I Version 3.1 7/2015 Teldat S.A. Teldat H1 RAIL...
- Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
-
Page 3: Table Of Contents
Safety information ....... . 20 Recycling and the Environment ......Teldat H1 RAIL... - Page 4 Table of Contents Teldat S.A. Translated Safety Warnings ......Teldat H1 RAIL...
-
Page 5: I Important Information
Note Please note that when the device operates for prolonged periods of time under extreme conditions (including high temperature and humidity) the service life of the device falls significantly. Teldat H1 RAIL... -
Page 6: Description
1.1 Introduction The Teldat H1 RAIL router is an IP router conceived to work in hostile and extreme environments and designed to be installed in rolling stock. Thanks to its ruggedized mechanics and special characteristics, allowing it to bear ex- treme temperatures, this router is particularly suited for: rolling stock, automotive applications, industrial environ- ments, industrial telecontrol, distribution installations for electricity, gas, water, etc. -
Page 7: Installation
Connect the power supply cable to the power supply. 2.1.1 Connecting the power The Teldat H1 RAIL router family is powered by an 110 V nominal DC power source. This device has no on/off switch or fuse. To comply with electrical safety regulations, this equipment must be connected to the vehicle power network through a 1 amp approved thermo-magnetic circuit breaker (ABB-S281-UC-K-1 or equivalent). -
Page 8: Data Connection
The Teldat H1 RAIL router has the following available data connectors: 2.1.2.1 LAN SWITCH The Teldat H1 RAIL router incorporates a 4 port Switch, 10/100BaseT with automatic MDI/MDIX to connect to a loc- al area network (LAN). This device has a LINK LED indicating the state of the connection. -
Page 9: Connecting To A Wwan Antenna
2.1.2.2 AUX The Teldat H1 RAIL router family has a DB9 female connector on the front panel labeled AUX. This can be used as a configuration port for the router or as a V.24 asynchronous serial port by means of a configuration command. The behavior or functionality of this interface must be previously configured. - Page 10 7 cms and the maximum recommended distance is 25 cms. In order to achieve optimum features, the installed radio frequency accessories (antennas and cables) should be those recommended by Teldat. The following image shows you where to find the antenna connectors for the WWAN modules.
-
Page 11: Connecting The Wlan Antenna
2.1.4 Connecting the WLAN antenna The Teldat H1 RAIL has N connectors to connect up to 2 WLAN (Wi-Fi) antennas in the models that have this inter- face. The device does not have internal antennas, so the installation of antennas in the Teldat H1 RAIL routers is essen- tial in order to improve the quality of the signal received and transmitted by the Wireless LAN module. - Page 12 • Configure the Ethernet interface on the IP terminal (normally a PC) using the IP address from the following range [192.168.1.2, 192.168.1.254] and mask 255.255.255.0. E.g. 192.168.1.2, 255.255.255.0. • Connect the IP terminal’s Ethernet interface to any of the Ethernet Switch ports on the Teldat H1 RAIL router (the LAN1..4 connectors) through an appropriate Ethernet cable (M12 to RJ45).
-
Page 13: Installing The Sim Card
Teldat S.A. 2.2 Installing the SIM card The Teldat H1 RAIL has one or two Wireless WAN interfaces. For them to operate, you may have to insert at least one SIM card in the device. There are certain services (CDMA) provided by several carriers in some countries that do not require SIM cards. In installations where a SIM card is required, you must always insert at least one. -
Page 14: Installing The Sim
SIM card on it. The steps are as follows: (1) Push the fastening to the right (OPEN) until the tray is released. (2) Open the upper part of the tray. (3) Fully insert the SIM card using the guides. Teldat H1 RAIL... -
Page 15: Closing The Device
(2) Refit the lid, first sliding it horizontally and then vertically so as not to ‘drag’ it over the Pad. (3) Replace the seven screws holding the cover. Example of a Thermal Pad assembled over the WWAN MD1. This must be assembled in both. Fig. 11: Teldat H1 RAIL... -
Page 16: Meaning Of The Leds
Teldat S.A. Chapter 3 Meaning of the LEDs The following figure shows the positions of the LEDs on the front panel of the device: Teldat H1 Rail: Front panel Fig. 12: Wireless WAN interface channel 0 (cellular10/1). OFF: Interface not available, not installed or not registered ON Registered, or registered and connected in the SIM operator Network. -
Page 17: Microswitches
This block of micros-witches can be found inside the Teldat H1 RAIL routers. You need to remove the top casing in order to handle them, following the instructions set forth in section Installing the SIM on page 10. - Page 18 On reaching this point, you can set micro-switch ‘5’ in the OFF position (you don’t have to power off the device). This way, the saved configuration will run next time you restart the device. Also, bear in mind that the device configuration is ignored on start up but it is not deleted. Teldat H1 RAIL...
-
Page 19: Appendix A Technical Information
Check that the SIM tray configuration is correct. A.2 Maintenance The Teldat H1 RAIL routers are designed to be highly available and durable. Therefore, they do not have any mov- ing parts. This design makes any maintenance unnecessary. A.2.1 Upgrading the software The Teldat H1 RAIL router family can be upgraded to new software releases. -
Page 20: Lan Connector
The installed WWAN connector type is N female coaxial. Signal N Connector Internal RF In/Out External A.3.4 WLAN Connectors The installed WWAN connector type is N female coaxial in those devices equipped with this interface. Signal N Connector Internal RF In/Out External Teldat H1 RAIL... -
Page 21: Gps Connector
Depending on the wireless WAN version the device has incorporated. Please see the manual on the appropriate module. CONNECTOR Up to 4 coaxial connectors, type N ANTENNA The antennas are supplied independently to the device Wireless LAN Interface Teldat H1 RAIL... - Page 22 +110 V DC INPUT CURRENT 150 mA @110 V DC MAXIMUM POWER 15 W Dimensions and Weight TYPE Ruggedized casing for 19” rack LENGTH x WIDTH x HEIGHT 240 x 445 x 44 mm WEIGHT 3.8 kg Teldat H1 RAIL...
- Page 23 Technical Information Teldat S.A. Environmental Specifications AMBIENT TEMPERATURE ON: -25 °C to 70 °C In storage: -30 °C to 85 °C RELATIVE HUMIDITY Annual average < 75 % During 30 consecutive days per year < 95 % Teldat H1 RAIL...
-
Page 24: Appendix B Safety Information
B.1 Recycling and the Environment Please do not, under any circumstances, throw away any Teldat H1 RAIL with normal domestic waste. Ask your loc- al town hall for information on how to correctly dispose of them in order to protect the environment against e-waste. - Page 25 Safety information Teldat S.A. B.2 Translated Safety Warnings Connections Teldat H1 RAIL...
- Page 26 Safety information Teldat S.A. Teldat H1 RAIL...
