A.3.5 GPS connector

The GPS connector installed (for devices equipped with this interface) is an FME female.
PIN
Internal
External
A.3.6 Configuration connector
The configuration connector installed is a DB9 female.
PIN
2
3
5
A.4 Technical specifications
Hardware architecture
PROCESSORS
MEMORY
STORAGE UNIT
LAN interface
PROTOCOLS
PORTS
SPEED
CONNECTOR
Wireless WAN interface
STANDARDS
Teldat H2 RAIL
RF In/Out
Gnd
Signal
RF In
Gnd
Signal
TxD (Output)
RxD (Input)
GND
Freescale QorIQ processor.
256 MB in DDR3.
FLASH Memory (32 Mbytes).
Ethernet (802.3).
4-port switch managed through MDI/MDX autodetection.
10/100/100 Mbps (BaseT).
M12 8P X-Code female connector.
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE ... Depending on the WWAN ver-
sion in the device.
RF FME male connector
DB 9 female
