Appendix B Radio information

B.1 RF specifications
The LTE and WCDMA features are provided by two modules described below:
Technology: LTE provided by Sierra Wireless MC7455.
Bands
Band 1
Band 3
Band 7
Band 20
Technology: LTE provided by Sierra Wireless MC7430
Bands
Band 1
Band 3
Band 7
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+provided by Sierra Wireless MC7455
Bands
Band 1
Band 3
Band 8
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+provided by Sierra Wireless MC7430
Bands
Teldat H2 RAIL
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
Tx: 832–862 MHz
Rx: 791–821 MHz
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 170–1785 MHz
Rx: 1805–1880 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Frequencies
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+22 dBm ± 1 dB
+23 dBm ± 1 dB
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+22 dBm ± 1 dB
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+23 dBm ± 1 dB
Conducted Transmit Power
Radio information
