Chapter 2 Teldat H2 Rail

2.1 Introduction

This manual shows you how to install and connect the Teldat H2 RAIL router.
Teldat H2 RAIL: Outer features
Fig. 1:

2.1.1 Power supply

For further information on the Teldat H2 RAIL power supply, please see

2.1.2 Hardware monitoring

The LEDs on the front panel are used to monitor the hardware in the Teldat H2 RAIL. These LEDs provide visual in-
formation regarding the state of the hardware components, indicating whether there is connectivity, data flow, etc.
For further information on said LED panel, please see
Teldat H2 RAIL
Connecting the power supply
LEDs on page 5.
2 Teldat H2 Rail
on page 7.
3
