A.3 Connectors
A.3.1 POWER connector
The power connector installed in the device is an M12 4-pole code A connector.
PIN
1
2
3
4
A.3.2 LAN connector
The Teldat 5Ge-Rail has two Ethernet interfaces. These are used to connect individual PCs or other switches.
The connection is made via an M12 8P X-Code female socket.
The pin assignment is as follows:
PIN
1
2
3
4
5
6
7
8
A.3.3 WWAN antenna connector
The Teldat 5Ge-Rail has up to four QMA female connectors installed.
Teldat 5Ge-Rail Router
Signal
+ V DC
+ V DC
0 V
0 V
GE Signal -> Signal
BI-DA+ -> Tx+ (1)
BI-DA- -> Tx- (2)
BI-DB+ -> Rx+ (3)
BI-DB- -> Rx-(6)
BI-DD+(4)
BI-DD-(5)
BI-DC-(7)
BI-DC+(8)
PIN
M12 4P A Code male
M12 8P X-Code female connector
ANT
Technical Information
