Optional SGI Remote Services (SGI RS)

007-5806-004
CMC 1
CMC 0
Figure 1-6
Blade Enclosure Chassis Management Board Locations
The primary PCIe based I/O sub-systems are sited in the administrative controller server, rack
leader controller and service node systems used with the blade enclosures. These are the main
configurable I/O system interfaces for the SGI ICE X systems. See the particular server's user
guide for detailed information on installing optional I/O cards or other components.
Note that each blade enclosure pair is configured with either two or four InfiniBand switch blades.
The optional SGI RS system automatically detects system conditions that indicate potential future
problems and then notifies the appropriate personnel. This enables you and SGI global support
teams to proactively support systems and resolve issues before they develop into actual failures.
SGI Remote Services provides a secure connection to SGI Customer Support - on demand. This
can ensure business continuance with SGI systems management and optimization.
Optional SGI Remote Services (SGI RS)
CMC-0 CMC-1 ACC CNSL RES HB PG
13
