007-5806-004
System
LEDs
1 2
System Main
reset power
Figure 5-3 SGI Rackable C1104G-RP5 1U Service Node Front and Rear Panels
1 2
Figure 5-4
SGI Rackable C1104G-RP5 System Control Panel and LEDs
From left to right the LED indicators are:
• Overheat/fan fail/UID
• LAN1 and LAN2 network indicators
• Hard drive activity and power good LEDs
Four disk drive bays
IPMI PCIe low-profile
LAN expansion slot
USB Ethernet VGA
ports ports port
1U Service Nodes
Optional GPU or
x16 full-height PCIe slot
73
