Replacing ICE X System Components
3. Slide a new blower assembly completely into the open slot, see Figure 7-5.
4. Tighten the blower assembly screw to secure the new fan.
Note: If you disconnected the AC power to the rear fan assembly prior to the replacement
procedure, all the fans will come on and run at top speed when power is reapplied. The speeds will
readjust when normal communication with the blade pair enclosure CMC is fully established.
A B
Tighten screw
Figure 7-5 Replacing an Enclosure Fan
007-5806-004 101
