Console Connections

007-5806-004
The flat panel console option (see Figure 1-1) has the following listed features:
1. Slide Release - Move this tab sideways to slide the console out. It locks the drawer closed
when the console is not in use and prevents it from accidentally sliding open.
2. Handle - Used to push and pull the module in and out of the rack.
3. LCD Display Controls - The LCD controls include On/Off buttons and buttons to control
the position and picture settings of the LCD display.
4. Power LED - Illuminates blue when the unit is receiving power.
Figure 1-1
Flat Panel Rackmount Console Option
1
2
4
Console Connections
3
3
