A: Technical Specifications and Pinouts

ICE X M-Rack Technical Specifications

110
Table A-4 provides information on the individual physical specifications of the compute racks
used in an M-Cell assembly. Table A-5 on page 111 lists the environmental specifications for an
individual M-Rack.
Table A-4 SGI ICE X M-Rack Physical Specifications
Characteristic
Height
Width
Depth
Weight (full)
Shipping weight (max)
Voltage range
Nominal
Tolerance range
Frequency
Nominal
Tolerance range
Phase required
Power requirements (max) 76 kVA (77.47 kW)
Hold time
Power cable
Power receptacle
Single power option
Three-phase option
Specification
93 in. (236.2 cm)
33 in. (83.8 cm)
48.4 in. (121.9 cm)
~2,426 lbs. (1,103 kg) approximate
~2,850 lbs. (1,295 kg) approximate
North America/International
200-240 VAC /230 VAC
180-264 VAC /180-254 VAC
North America/International
60 Hz / 50 Hz
47-63 Hz / 47-63
single-phase or optional 3-phase
20 ms
10 ft. (3.0 m) pluggable cords
North America/Japan | International
Maximum 8, 30-Amp | Maximum 8, 32-Amp
NEMA L6-R30 _____| NEMA IEC60309
(2) 60-Amp 4-wire __| (2) 32-Amp 5-wire
IEC60309 _________| IEC60309
007-5806-004
