A: Technical Specifications and Pinouts

D-Rack Physical and Power Specifications

108
Table A-2 shows the physical specifications of the SGI ICE X system based on the D-Rack.
Table A-2 ICE X System D-Rack Physical Specifications
System Features (single rack)
Height
Width
Depth
Weight (full) maximum
Shipping weight maximum
Shipping height maximum
Shipping width
Shipping depth
Voltage range
Nominal
Tolerance range
Frequency
Nominal
Tolerance range
Phase required
Power requirements (max)
Hold time
Power cable
Access requirements
Front
Rear
Side
Specification
79.5 in. (201.9 cm) 82.25 in (208.9 cm) with 2U top
24.0 in. (61 cm) - air and water cooled
49.5 in. (125.7 cm) - air cooled; 50.75 in. (128.9 cm) - water cooled
~2,500 lbs. (1,136 kg) approximate (water cooled)
~2,970 lbs. (1,350 kg) approximate maximum
88.75 in. (225.4 cm)
44 in. (111.8 cm)
62.75 in. (159.4 cm)
North America/International
200-240 VAC /230 VAC
180-264 VAC /180-254 VAC
North America/International
60 Hz /50 Hz
47-63 Hz /47-63 Hz
3-phase (optional single-phase available in I/O rack)
34.58 kVA (33.89 kW)
16 ms
12 ft. (3.66 m) pluggable cords
48 in. (121.9 cm)
48 in. (121.9 cm)
None
007-5806-004
