3: System Overview
28
Blade enclosure pair
CMC-0
CMC-1
ACC
CNSL RES HB PG
CMC-0
CMC-1
ACC
CNSL RES HB PG
Figure 3-2
D-rack Blade Enclosure and Rack Components Example
42U High Rack
Service node
Admin server
Rack leader controller
1U Gig-E switch
1U Gig-E switch
1U console
Blade enclosure
pair
007-5806-004
