Levelflex FMP51, FMP52, FMP54 FOUNDATION Fieldbus
Endress+Hauser
Schritt Block
6 SETUP (TRDSUP)
7 SETUP (TRDSUP)
8 SETUP (TRDSUP)
9 SETUP (TRDSUP)
10 SETUP (TRDSUP)
11 SETUP (TRDSUP)
12 SETUP (TRDSUP)
13 SETUP (TRDSUP)
14 SETUP (TRDSUP)
15 SETUP (TRDSUP)
1) only available for devices with "interface measurement" application package
2) only available for coated probes and "Tank type" = "Bypass/pipe"
12.8

Configuration of the on-site display

12.8.1

Factory settings of the on-site display for level measurements

Parameter Factory setting for devices with 1 current
output
Format display 1 value, max. size
Value 1 display Levele linearized
Value 2 display Distance
Value 3 display Current output 1
Value 4 display None
The on-site display can be adjusted in the DISPLAY (TRDDISP) transducer block.
Commissioning (block-based operation)
Parameter
Distance to upper connection
(distance_to_upper_connection)
DC value (dc_value)
Empty calibration
(empty_calibration)
Full calibration (full_calibration)
Level (level)
Interface (interface)
Distance (filtered_dist_val)
Interface distance
(interface_distance)
Signal quality (signal_quality)
Confirm distance (confirm_distance) Compare the displayed distance to the
Factory setting for devices with 2 current
outputs
1 value, max. size
Levele linearized
Distance
Current output 1
Current output 21
Aktion
• For measurements in bypasses:
Enter the distance from the
reference point R to the lower edge
of the upper connection.
• Otherwise: Keep the factory setting.
Enter dielectric constant of the upper
medium.
Enter the distance E between the
reference point R and the minimum
level (0%).
Enter distance F between the
minimum (0%) and maximum (100%)
level.
Displays the measured level L.
Displays the interface height L .
I
Displays the distance D between the
reference point R and the level L.
Displays the distance D between the
I
reference point R and the interface L
Displays the signal quality of the level
echo.
real distance in order to start the
recording of the mapping curve.
Selection:
• 179: Manual map
• 32847: Delete all
• 32859: Distance ok
• 32860: Distance too big
• 32861: Distance too small
• 32862: Distance unknown
• 33100: Tank empty
.
I
113
