9.6.6 Expert Information Transducer Block
The parameters of the Expert Information Transducer Block are described in
GP01015F: "Levelflex FMP5x - Description of Device Parameters - FOUNDATION
Fieldbus"
Label
Absolute echo amplitude
Absolute EOP amplitude
Application parameter
Electronic temperature
EOP shift
Found echoes
Max. electronics temperature
Time max. electronics temperature
Measurement frequency
Min. electronics temperature
Time min. electronics temperature
Relative echo amplitude
Relative interface amplitude
Reset min./max. temp.
Noise of signal
Used calculation
Tank trace state
Max. draining speed
L max. fill speed
Time max. level
Max. level value
Time min. level
Min. level value
Reset min./max.
I max. drain speed
I max. fill speed
Time max. interface
Max. interface value
Time min. interface
Min. interface value
Application parameter
Operating mode
Temperature unit
Activate SW option
Status
Status
Status
Integration into a FOUNDATION Fieldbus network
Index Data type Size (Bytes) Storage Class Write
51 FLOAT 4
55 FLOAT 4
58 FLOAT 4
74 ENUM16 2
66 FLOAT 4
69 FLOAT 4
71 ENUM16 2
73 FLOAT 4
75 STRING
76 FLOAT 4
77 FLOAT 4
78 STRING
53 FLOAT 4
60 FLOAT 4
79 ENUM16 2
63 FLOAT 4
80 ENUM16 2
81 ENUM16 2
82 FLOAT 4
83 FLOAT 4
84 STRING
85 FLOAT 4
86 STRING
87 FLOAT 4
94 ENUM16 2
88 FLOAT 4
89 FLOAT 4
90 STRING
91 FLOAT 4
92 STRING
93 FLOAT 4
95 ENUM16 2
108 ENUM16 2
72 ENUM16 2
110 UINT32 4
56 ENUM8 1
61 ENUM8 1
64 ENUM8 1
MODE_BLK
