Levelflex FMP51, FMP52, FMP54 FOUNDATION Fieldbus
3) For FMP54 with gas phase compensation (product structure: feature 540 "Application Package", option EF or EG) a map must NOT be recorded.
Endress+Hauser
10. Navigate to: Setup → Distance
 Displays the distance D between the reference point R and the level L.
11. Navigate to: Setup → Signal quality
 Displays the signal quality of the level echo.
12. For operation via local display:
Navigate to: Setup → Mapping → Confirm distance
 Compare the displayed distance to the real distance in order to start the
recording of the mapping curve if required
13. For operation via operating tool:
Navigate to: Setup → Confirm distance
 Compare the displayed distance to the real distance in order to start the
recording of the mapping curve if required
Commissioning via operating menu
3)
.
3)
.
