Aux. Connector
Fig. 24:

3.8 Installing the SIM card

The Teldat-iM8 is equipped with a Wireless WAN interface that may need a SIM card to be inserted in order to oper-
ate. Certain services (CDMA) provided by several carriers in some countries do not require SIM cards.
The Teldat-iM8 is equipped with two SIM trays.
One is located on the rear panel of the router, as shown in the following figure.
External module SIM tray
Fig. 25:
To insert the SIM card in the external SIM tray, first place the device so you can see the rear panel and then carry
out the following steps:
(1) Press the button until the SIM tray comes out.
(2) Place the SIM on the tray.
(3) Insert the tray in the slot and return the tray to its original position.
Inserting the SIM in the external module
Fig. 26:
The other SIM tray is internal. To access it, you need to access the underside of the router, open the flap (shown in
the following figure) and insert the SIM card.
Teldat Router iM8
3 Components and Power Supply
19
