Technical Information

A.5.2 LAN Interface

PROTOCOLS
PORTS
SPEED
CONNECTOR
A.5.3 WAN Base-T Interface
STANDARDS
SPEED
CONNECTOR
A.5.4 WAN SFP Interface
STANDARDS
SPEED
TYPES
CONNECTOR
A.5.5 Wireless WAN Interface
STANDARDS
SPEED
CONNECTOR
ANTENNA
A.5.6 Wireless LAN Interface
STANDARDS
FREQUENCY
SPEED
CONECTOR
32
Ethernet (802.3)
8 port Switch managed with MDI/MDX auto-detection.
10/100/1000 Mbps (BaseT)
RJ45 female.
Ethernet (802.3)
10/100/1000 Mbps (BaseT)
RJ45 female.
802.1Q (VLAN)
1000-Base-X
1000 Mbps full duplex.
LX/LH (single-mode 1310 nm).
SX (multi-mode 850 nm).
ZX (single-mode 1550 nm).
RJ11 female.
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE ... Depends on the wireless WAN
version of the device.
Depends on the wireless WAN version of the device. Please read the manual on
the relevant module.
2 RF SMA female per module.
Depends on the type of wireless WAN module installed. Please refer to the an-
tenna catalog for cellular interfaces.
802.11abgn
2.4 GHz / 5 GHz
Depends on the Wireless LAN module.
Up to 4 RF RP-SMA female.
