Cell
Storage (HD/SD)
Apps
Slot
Teldat Router iM8
SFP
Status
RSSI
SIM
Tricolor
Tricolor
Tricolor
Tricolor
Tricolor
Tricolor
Tricolor
3 Components and Power Supply
Green -> connected. Blink-
ing: connection data activ-
ity.
Off -> not used.
Off -> system stopped.
Red -> interface is unavail-
able because it is installing,
it is disabled (shutdown) or
due to auto-test failure.
Amber -> idle.
• Rapid blinking. It has not
registered in the network
or the quality is insuffi-
cient.
• Slow blinking. GSM con-
nection (GPRS).
• Steady. WCDMA (UMTS /
HSDPA) connection.
Green -> connected. Blink-
ing: connection data activ-
ity.
Green -> Good level.
Amber -> Fair level.
Red -> Critical level.
Green -> External SIM.
Amber -> Internal SIM.
Off -> Hard disk or
SD card is not connected or
is inactive.
Green -> Detected hard
disk or SD card.
Amber -> Testing hard disk
or SD card.
Red -> Error.
Off -> no applications de-
tected.
Green -> applications de-
tected.
Amber -> testing applica-
tion.
Red -> application error.
Off -> There is no card in
the expansion slot.
