3 Components and Power Supply
USB
Wi-Fi 1
Wi-Fi 2
LAN Switch
Eth WAN
6
Base-t
Tricolor
Bicolor
Bicolor
Tricolor
Tricolor
and operating.
Off -> system stopped.
Red -> interface is unavail-
able because it is installing,
it is disabled (shutdown) or
due to auto-test failure.
Amber -> idle.
• Rapid blinking. It has not
registered in the network
or the quality is insuffi-
cient.
• Slow blinking. GSM con-
nection (GPRS).
• Steady. WCDMA (UMTS /
HSDPA) connection.
Blinking (green/red) ->
activity/maintenance.
Off -> Interface not avail-
able or not installed (not
supported).
Red -> Interface not found,
no data connection.
Amber -> Connecting.
Green -> Communications
established. Blinking: de-
pends on the activity.
Off -> Interface not avail-
able or not installed (not
supported).
Red -> Interface not found,
no data connection.
Amber -> Connecting.
Green -> Communications
established. Blinking: de-
pends on the activity.
Green -> connected. Blink-
ing: connection data activ-
ity.
Red -> disconnected.
Off -> interface off.
Green -> connected. Blink-
ing: connection data activ-
ity.
Off -> not used.
