A.5.7 USB Interface

3G USB MODEMS
SPEED
CONNECTOR
A.5.8 Configuration Interface
LOCAL TERMINAL
CONNECTOR
A.5.9 Power Supply
INPUT VOLTAGE
INPUT CURRENT
JACK
INTERNAL PIN
A.5.10 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.5.11 Environmental Specifications
TEMPERATURE
RELATIVE HUMIDITY
Teldat Router iM8
Please visit the Teldat website http://www.teldat.com to get a list of the supported
3G USB modems.
The interface complies with the USB 2.0 (480 Mbps) standard; the end speed de-
pends on the 3G USB modem used.
USB Type A.
V.24 9600-8-N-1 without flow control.
RJ45 female on the device front panel.
+12V DC
1200 mA
5.5 mm
2.5 mm
Desktop / chassis for a 1 U high Rack mount enclosure.
245 x 210 x 45 mm
1.4 kg
OPERATING NORMALLY: 0 ºC to 45 ºC.
STORED: -25 ºC to 70 ºC.
On: 5 % to 90 %.
