Teldat S.A.
Note
Some devices leave the factory with a customized configuration for a specific client. This personaliza-
tion can mean that the default configuration is different from the one shown above.
This initial configuration allows you to access the device configuration console through the Telnet IP protocol. To do
this, carry out the following steps:
• Configure the IP terminal Ethernet interface (normally a PC) with IP address in the range of 192.168.1.2,
192.168.1.254 and mask 255.255.255.0. E.g. 192.168.1.2, 255.255.255.0.
• Connect the IP terminal Ethernet interface to any of the Teldat C1+LS router Ethernet Switch ports (connectors
LAN 1...4) through the Ethernet cable (RJ45) supplied with the device.
• Start a Telnet session from the IP terminal towards IP address 192.168.1.1 ( Teldat C1+LS router default address).
• The default configuration does not request access credentials (user/password) to access the console.
For further information on how to fully configure the device, please see the manuals included on the CD supplied with
the Teldat C1+LS router.

1.2.4 Installing the SIM card

The Teldat C1+LS has a Wireless WAN interface, which means that at least one SIM card must be inserted in the
device for it to work. There are certain services (CDMA) from several operators in some countries that do not require
SIM cards.
The Teldat C1+LS has a SIM tray located inside the device.
In installations where a SIM card is required, you must always install a SIM card.
Warning
This device is compatible with a 1.8V and a 3V SIM. Do not install a SIM that doesn't support these
voltages.
Warning
Never install the SIM card when the device is switched on.
Always disconnect the device from the main power supply before inserting the internal SIM.
Always disconnect the device before removing the casing to get to the internal SIM.
When inserting the SIM card, please protect yourself against electrostatic discharges (ESD).
Do not touch the SIM card connectors.
1.2.4.1 Installing the internal SIM
To access the internal SIM, you need to dismantle the upper outer casing. To do this, unscrew the holding screws
that are located on the front and the back of the device. The SIM tray is located on the main printed circuit board.
Teldat C1+LS Router
• IP address: 192.168.1.1
• IP mask: 255.255.255.0
1 Installing the Router
9
