Cisco TelePresence SX20 Codec

Introduction

xConfiguration UserInterface OSD Output

Define on which monitor the on-screen information and indicators (OSD) should be displayed.
Requires user role: ADMIN
Default value: Auto
USAGE:
xConfiguration UserInterface OSD Output:
where
: Auto/1/2
Output
Auto: The system detects when a monitor is connected to a video output, and sends
the on-screen information and indicators to the first monitor you connect. If you have
a multi-monitor setup, and all monitors are connected before switching on the system,
the on-screen information and indicators are sent to the video output with the lowest
number, starting with Output Connector 1 (HDMI 1).
Range 1-2: The system sends the on-screen information and indicators to the speci-
fied output. Choose n to send the on-screen information and indicators to the system's
Output Connector n.
SX20 Codec API Reference Guide CE8.3, JANUARY 2017.
D15316.05
About the API xConfiguration xConfiguration
Output
xCommand

UserManagement configuration

xConfiguration UserManagement LDAP Mode

The video system supports the use of an LDAP (Lightweight Directory Access Protocol) server
as a central place to store and validate user names and passwords. Use this setting to config-
ure whether or not to use LDAP authentication. Our implementation is tested for the Microsoft
Active Directory (AD) service.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration UserManagement LDAP Mode:
where
: Off/On
Mode
Off: LDAP authentication is not allowed.
On: Use LDAP authentication.

xConfiguration UserManagement LDAP Server Address

Set the IP address or hostname of the LDAP server.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration UserManagement LDAP Server Address: "Address"
where
: String (0, 255)
Address
A valid IPv4 address, IPv6 address or hostname.
95
