xConfiguration Conference MaxTotalReceiveCallRate

This configuration applies when using a video system's built-in MultiSite feature (optional) to
host a multipoint video conference.
Define the maximum overall receive bit rate allowed. The bit rate will be divided fairly among
all active calls at any time. This means that the individual calls will be up-speeded or down-
speeded as appropriate when someone leaves or enters a multipoint conference, or when a call
is put on hold (suspended) or resumed.
The maximum receive bit rate for each individual call is defined in the Conference
MaxReceiveCallRate setting.
Requires user role: ADMIN
Default value: 6000
USAGE:
xConfiguration Conference MaxTotalReceiveCallRate:
where
: Integer (64..6000)
MaxTotalReceiveCallRate
The maximum receive call rate (kbps).

xConfiguration Conference MaxTotalTransmitCallRate

This configuration applies when using a video system's built-in MultiSite feature (optional) to
host a multipoint video conference.
Define the maximum overall transmit bit rate allowed. The bit rate will be divided fairly among
all active calls at any time. This means that the individual calls will be up-speeded or down-
speeded as appropriate when someone leaves or enters a multipoint conference, or when a call
is put on hold (suspended) or resumed.
The maximum transmit bit rate for each individual call is defined in the Conference
MaxTransmitCallRate setting.
Requires user role: ADMIN
Default value: 6000
USAGE:
xConfiguration Conference MaxTotalTransmitCallRate:
where
: Integer (64..6000)
MaxTotalTransmitCallRate
The maximum transmit call rate (kbps).
SX20 Codec API Reference Guide CE8.3, JANUARY 2017.
D15316.05
About the API xConfiguration xConfiguration
MaxTotalReceiveCallRate
MaxTotalTransmitCallRate
xCommand

xConfiguration Conference MultiStream Mode

The video system supports multistream video for conferences, provided that the conference
infrastructure supports the feature (Cisco TelePresence Server 4.2 or later). This means that
the video system can compose the video streams locally into a conference layout which utilizes
all available screens. This results in an enhanced user experience.
Multistream video is supported only via SIP.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Conference MultiStream Mode:
where
: Auto/Off
Mode
Auto: Use local composition of video streams if the feature is supported by the confer-
ence infrastructure.
Off: Local composition is disabled. Layouts will be transcoded by the conference infra-
structure (Cisco TelePresence Server).
