10 Accessories

A full range of accessories for various applications and industrial environments are available.
Accessories include items that may be ordered at any time and added on-site.
10.1 Accessories (all models)
•
•
10.1.1 Multi-Channel Box
The Multi-Channel Box can be used for all communication boxes. The box includes 8 sets of field
wiring terminals wired in parallel to one 5 m (16 ft) cable set to connect to the communication box.
MI3
info@Raytek-Direct.ca
Multi-Channel Box (XXXMI3CONNBOX)
USB/RS485 Adapter for boxes with RS485 interface (XXXUSB485)
Comm Box
Figure 40: Multiple Head Configuration with Comm Box
Multi-Channel Box
5 m
(16 ft)
Figure 41: Dimensions
Rev. F1 05/2013
Accessories
Head 1
Head 2
Head 8
55
