10.1.2 USB/RS485 Adapter

The USB/RS485 adapter is self-powering via the USB connection.
MI3
info@Raytek-Direct.ca
Correct position of the
shield before mounting
Figure 43: Correct Mounting of the Cable Shield
The total sensing head cable length for all networked sensing heads must not exceed 30
m/98 ft (for MI3) and 2x30 m/2x98 ft (for MI3M)!
Figure 44: USB/RS485 Adapter (XXXUSB485)
Rev. F1 05/2013
Accessories
Shield with metallic
contact to the grommet
57
