Accessories

6

6.1 Overview

For all models:
Mounting Nut
Fixed Mounting Bracket
Adjustable Bracket
Air Purge Collar
Right Angle Mirror
Sighting Viewer
Adjustable Pipe Adapter
ThermoJacket
Industrial Power Supply
Protective Window
Panel Mount Display
For Smart model:
PC communications software, HART/RS232 adapter
Sensor
Sensor with Air-/Water Cooled
Housing (Option)
26
Housing
for lens protection
Fixed Bracket
(XXXTXXACFB)
Adjustable Bracket
(XXXTXXACAB)
ThermoJacket and Accessories
(RAYTXXTJ3M)
Figure 19: Overview to the available accessories
Adjustable Pipe Adapter
Sighting Viewer
(XXXTXXACSV)
Right Angle Mirror
(XXXTXXACSV)
Air Purge Collar
(XXXTXXACAP)
Mounting Nut
(XXXTXXACMN)
Rev. O 06/2011
XXXTXXACMN
XXXTXXACFB
XXXTXXACAB
XXXTXXACAP
XXXTXXACRA
XXXTXXACSV
XXXTXXAPA
RAYTXXTJ3M
XXXTXACDCPS
RAYGPC/RAYGPCM
XXXTXACRCK
(XXXTXXAPA)
TX
