6 Outputs

For the outputs the following groupings (setups) are possible:
Output
OUT1
OUT2
TC
6.1 Analog Output OUT1
This output can be configured for the object or the head ambient temperature. E.g. the output range
for the head ambient temperature is 0 to 5 VDC corresponding to 0 to 500°C (32 to 932°F). The
minimum load impedance for the voltage output must be 10 kΩ.
The output is short circuit resistant.
6.2 Analog Output OUT2
The signal output can be configured as either current or voltage output. The minimum load
impedance for the voltage output must be 10 kΩ. The maximum current loop impedance for the mA
output is 500 Ω.
The output is short circuit resistant.
MI3
info@Raytek-Direct.ca
Setup 1
head temperature head temperature
V
object temperature object temperature
mA
−
Comm Box: metal
Source: object temperature / head ambient temperature
Signal: 0 to 5/10 V
Terminal:
OUT1, GND
The outputs <OUT1> and <TC> are not available at the same time!
Comm Box:
metal
Source: object temperature / head ambient temperature
Signal: 0/4 to 20 mA or 0 to 5/10 V
Terminal: OUT2, GND
Setup 2 Setup 3
object temperature
V V
object temperature
V mA
− −
Rev. F1 05/2013
Outputs
Setup 4 Setup 5
object temperature
−
V
object temperature head temperature
V V
object temperature
−
