17 Profinet

The Profinet fieldbus MI3 communication box (called fieldbus communicator) maps the object and
internal temperature of all pyrometer modules on Profinet IO. In the initialization phase, the fieldbus
communicator determines the physical structure of the node and creates a local process image with all
pyrometers.
The diagnostics concept is based on channel specific diagnostic messages that are mapped to the
respective alarms. Coding is done according to IEC 61158 Profinet IO.
Specification:
Type:
Conformance class:
Real-Time class:
Connection:
Transfer speed
Head support
Power supply:
17.1 Wiring
Details for the wiring you can find under Ethernet in section 16.1 Wiring, page 94.
17.1.1 Status LED
The status LED's are relevant for the Comm Box (DIN) only signalizing the following operating states.
MI3
info@Raytek-Direct.ca
Profibus IO
A
1 (RT) and the Real-Time class UDP
M12 or RJ45
electrically isolated
100 Mbit/s full-duplex, also with auto-negotiation
up to 8 pyrometer modules (MI3 or MI3100 sensing heads)
Configurable substitute value behavior for each pyrometer module in the
event of failure
12 to 24 V (500 mA max.)
yellow LED
green LED
off
off
on
1 Hz
on
on
Figure 82: Status LED's for the Comm Box (DIN)
Description
No communication
Waiting for configuration and parameters
Device is in data-exchange mode
Rev. F1 05/2013
Profinet
97
