ASCII Programming
The parameter will be stored into the device EEPROM.
E=0.975<CR> "E" is the parameter to be set
"=" is the command for "set a parameter"
"0.975" is the value for the parameter
<CR> (carriage return, 0Dh) is closing the request
Remark: It is possible to close with <CR> <LF>, 0Dh, 0Ah, but not necessary.
Setting a parameter without writing into the EEPROM (Poll Mode)
This function is for test purposes only.
E#0.975<CR> "E" is the parameter to be set
"#" is the command for "set parameter without writing into the EEPROM"
"0.975" is the value for the parameter
<CR> (carriage return, 0Dh) is closing the request.
Remark: It is possible to close with <CR> <LF>, 0Dh, 0Ah, but not necessary.
Device response format:
!E0.975<CR><LF>
"E" is the parameter
"0.975" is the value for the parameter
<CR> <LF> (0Dh 0Ah) is closing the answer.
Error message
*Syntax Error "*" is the character for "Error"
18.3 Device Information
This information is factory installed, read only.
18.4 Device Setup
18.4.1 Temperature Calculation
U=C unit for the temperature value
E=0.950 Emissivity setting (Caution: according to the settings for "ES", see section
18.4.3
XG=1.000 Setting for transmission
For the calculation of the temperature value, it is possible to set an offset (relative number to be added
to the temperature value), and a gain value.
DG=1.0000 Gain adjustment for the temperature signal
DO=0 Offset adjustment for the temperature signal
104
info@Raytek-Direct.ca
"!" is the parameter for "Answer"
Command Description
?HI Device name of the Head
?HN Serial Number of the Head
?XU Device name of the Box
?XV Serial Number of the Box
?XH Maximum Temp. Range: e.g. for LT head
?XB Minimum Temp. Range: e.g. for LT head
Table 15: Device Information
Emissivity Setting and Alarm Set points, page 105.)
Rev. F1 05/2013
Answer
(Example)
"HIMI3LTS22"
"HN98123"
"XUMI3"
"!XV0A0027"
"!XH0600.0"
"!XB-040.0"
