Technical Data

3.4.3 Comm Box (DIN)

Ambient Temperature
Storage Temperature
Relative Humidity
EMC
Vibration
Shock
Weight
Material
3.4.4 LTH Electronics
Ambient Temperature
Storage Temperature
Rating
3.5 Dimensions
3.5.1 Sensing Head LT, G5
Standard cable length
1 m (3 ft.)
Ø 5 mm (0.2 in)
3.5.2 Sensing Head LTH
Figure 3: Dimensions of LTH Sensing Head with separated Electronics
18
info@Raytek-Direct.ca
-10 to 65°C (14 to 149°F)
-20 to 85°C (-4 to 185°F)
10% to 95% non-condensing
EN 61326-1:2006
11 to 200 Hz, 3 g above 25 Hz operating, 3 axes / IEC 60068-2-6
50 g, 11 ms, operating, 3 axes / IEC 60068-2-27
125 g (4.4 oz)
molded plastic
-10 to 65°C (14 to 149°F)
-20 to 85°C (-4 to 185°F)
IP65 (NEMA-4) / IEC 60529
Figure 2: Dimensions of LT, G5 Sensing Heads
Rev. F1 05/2013
MI3
