3.4 Environmental Specification
3.4.1 Sensing Head
Ambient Temperature
LT, G5
LTH
1M, 2M
Laser (1M, 2M)
Storage Temperature
LTH
all other models
Rating
Relative Humidity
EMC
Vibration
Shock
Weight
LT, G5
1M, 2M
Material
Head
Head Cable
LTH
all other models
3.4.2 Comm Box (metal)
Ambient Temperature
Storage Temperature
Rating
Relative Humidity
EMC
Vibration
Shock
Weight
Material
MI3
info@Raytek-Direct.ca
-10 to 120°C (14 to 248°F)
-10 to 180°C (14 to 356°F)
0 to 120°C (32 to 248°F)
automatic switch off at 65°C (149°F)
-20 to 180°C (-4 to 356°F)
-20 to 120°C (-4 to 248°F)
IP65 (NEMA-4) / IEC 60529
10% to 95% non-condensing
EN 61326-1:2006
11 to 200 Hz, 3 g above 25 Hz operating, 3 axes / IEC 60068-2-6
50 g, 11 ms, operating, 3 axes / IEC 60068-2-27
50 g (1.8 oz)
233 g (8.2 oz)
Stainless steel
Teflon
®
PUR (Polyurethane), Halogen free, Silicone free
Teflon develops poisonous gasses when it comes into contact with flames!
-10 to 65°C (14 to 149°F)
-20 to 85°C (-4 to 185°F)
IP65 (NEMA-4) / IEC 60529
10% to 95% non-condensing
EN 61326-1:2006
11 to 200 Hz, 3 g above 25 Hz operating, 3 axes / IEC 60068-2-6
50 g, 11 ms, operating, 3 axes / IEC 60068-2-27
370 g (13 oz)
die-cast zinc enclosure
Rev. F1 05/2013
Technical Data
17
