<OUT1 Mode>
<OUT1 Source>
<OUT1 Value>
<OUT1 low temp.>
<OUT1 high temp.> defines the temperature for the high end of the analog output range (scaling)
<OUT2 Mode>
<OUT2 Source>
<OUT2 Value>
<OUT2 low temp.>
<OUT2 high temp.> defines the temperature for the high end of the analog output range (scaling)
<Interface>
<Factory default>
MI3
info@Raytek-Direct.ca
defines the mode for the analog output:
<TCJ>, <TCK>, <TCR>, <TCS>
<0-5V>
<0-10V>
<disable> output goes to high-resistance
assigns the selected head to the analog output:
<#1>, <#2>, ..., <Head
>
max
defines the basis for the output value:
<Tobject>: object temperature to be output
<Tambient>: head ambient temperature to be output
defines the temperature for the low end of the analog output range (scaling)
defines the mode for the analog output 2:
<0-20mA>
<4-20mA>
<0-5V>
<0-10V>
<disable> output goes to high-resistance
assigns the selected head to the analog output:
<#1>, <#2>, ..., <Head
>
max
defines the basis for the output value:
<Tobject>: object temperature to be output
<Tambient>: head ambient temperature to be output
defines the temperature for the low end of the analog output range (scaling)
RS485/Profibus/Modbus:
<address>: unique address of the box in the network.
<baudrate>: baud rate for the box. Each device in the network must be set to the
same baud rate. The baud rate for Profibus is automatically negotiated between
master and slave.
Profinet/Ethernet:
<DHCP>: on/off – network protocol to configure a device in a network. DHCP
is switched off for Profinet communications.
<IP address>: a unique address of the box in the network, only changeable at
DHCP = off
<SubNetMask>: the subnet mask defines the interpretation of the IP address,
only changeable at DHCP = off
<Gateway>: a gateway connects two subnets at different subnet addresses, only
changeable at DHCP = off
<Port>: communication port, only changeable at DHCP = off, read-onlyfor
Profinet communications
<MAC>: MAC address, read-only
sets the box back to factory default.
The factory default values are to be found in section 18.9
page 108.
Rev. F1 05/2013
Operation
Command
Set,
49
