Starting
address
<n>220
<n>230
<n>240
<n>250
<n>260
<n>270
<n>280
<n>290
<n>300
<n>310
<n>320
MI3
info@Raytek-Direct.ca
Size Modbus Data
[bits] Access Type
16 holding char
register
32 holding float
register
32 holding float
register
32 holding float
register
32 holding float
register
32 input register integer Power / AD value
32 holding float
register
32 holding float
register
16 holding short
register
32 holding float
register
32 holding float
register
Content Values
Emissivity Source I: internal command
E: ext. input (0V .. 5V)
D: digital selected FTC1-3
Presel. Emissivity 0.1 .. 1.1
Valley hold time 0.0 .. 998.9s (999: infinite)
Average time 0.0 .. 999.0 [seconds]
Peak hold time 0.0 .. 998.9 [seconds] (999: infinite)
Presel. Setpoint
Transmissivity 0.1 .. 1.0
FTC3 trigger/hold 1: trigger, 2: hold
Setpoint relay function number within range <n>060 .. <n>070 XS
Adv. hold hysteresis
Rev. F1 05/2013
Modbus
MI3[M]
command
ES
EV
F
G
P
Q
SV
XG
XN
XY
