6.5 Thermocouple Output TC
This output can be configured as thermocouple output type J, K, R, or S. For that output, you must
install a dedicated compensation cable. The output impedance is 20 Ω. The output is short circuit
resistant.
MI3
info@Raytek-Direct.ca
Comm Box: metal
Source:
object temperature
Signal: TCJ, TCK, TCR, or TCS
Terminal: TC, GND
The outputs <OUT1> and <TC> are not available at the same time!
