ASCII Programming
Examples for the head command "Emissivity":
?2E requests the emissivity for sensing head at address 2
2E=0.975 sets the emissivity to 0.975 for sensing head at address 2
!2E0.975 sensing head at address 2 confirms the emissivity setting
18.8 Addressing of Multiple Boxes (RS485)
Up to 32 communication boxes can be connected within an RS485 network. To direct a command to
one box among the 32 possible, it is necessary to „address" a command. Therefore, a 3-digit number is
set prior the box command. The 3-digit number is determined between 001 and 032.
XA=024 will set address to 24 (box must not be in multidrop mode)
Changing an address:
(e.g. the address is changed from 17 to 24)
command answer
„017?E" „017E0.950"
„017XA=024" "017XA024" setting of a new address
„024?E" „024E0.950"
Note: A box with the address 000 is a single box and not in multidrop mode.
If a command is transferred, starting with the 3-digit number 000, all boxes (with addresses from 001
to 032) connected will get this command – without to send an answer.
command answer
"024?E" "024E0.950"
"000E=0.5" will be executed from all units, no answer
"024?E" "024E0.500"
"012?E" "012E0.500"
18.9 Command Set
P ... Poll, B ... Burst, S ... Set, N ... Notification
n ... head number, v ... value, X ... uppercase letter
Description
Poll parameter
Set parameter
Error message
Acknowledge message !
Burst string format
Ambient background
temp. compensation
Advanced hold with
average
Control ambient
background temp.
compensation
108
info@Raytek-Direct.ca
Char Format P B S N Legal Values
? ?X
√
= X=...
*
$ ?$ or
√
$=nT
A nA
√ √ √
float
AA nAA
√ √ √
float
AC nAC
√ √ √
Rev. F1 05/2013
?T
BR=115200
√
*Syntax error
!BR115200
√
°C/°F
0 – 999.9 s
0 – sensor temp.
1 – via number
2 – via ext. input
Factory default Head /
Box
TIXJXT
23°C H
000.0s H
0 H
MI3
