12 DataTemp Multidrop Software

12.1 Software Features
DataTemp Multidrop DTMD provides sensor setup, remote monitoring, and simple data logging for
analysis or to meet quality record-keeping requirements. Additional features configurable with
DTMD Software:
•
•
•
•
For more detailed information, see the comprehensive help feature in the DTMD software.
12.2 PC Requirements
•
•
•
12.3 USB Driver Installation
Before running the DTMD Software the installation of an adequate USB driver is required, see section
5.6 USB, page 34.
12.4 Software Launch
Make sure any sensor is turned on and the USB driver is installed before running DTMD software.
The Startup Wizard runs the first time you use the program. Please note:
• The wizard shows active COM ports only!
• The sensor requires the selection of <ASCII protocol>!
• The DTMD software communicates to Comm Boxes only! A multidrop installation is related to a
MI3
info@Raytek-Direct.ca
Eight-position "recipe" table that can be easily interfaced to an external control system
External reset signal input FTC for signal processing
External inputs FTC for analog emissivity adjustment or background radiation compensation
Remote digital communication and control of up to 32 sensors in an RS485 multidrop
configuration
PC with Windows 2000/XP/Vista/Win7, 64 MB RAM memory
about 10 Mb free memory on the hard disc for program files
USB port with recommended USB/RS485 adapter (available as accessory), see section
10.1.2 USB/RS485 Adapter, page 57.
network with multiple Comm Boxes and not to a multiple head system with one Comm box only!
