Installation
The cable must include shielded wires. It should not be used as a strain relief!

5.4.1 Comm Box (metal)

26
info@Raytek-Direct.ca
Figure 14: Terminal Wiring for the Comm Box
Rev. F1 05/2013
Sensing Head
Emissivity Control
Ambient Compensation
Trigger/Hold
T T T /T
obj head obj head
Alarm: T / T
obj head
Power Supply
MI3
