Operation
The head number is shown only if two or more sensing heads are connected to the communication
box.
Symbol/Message
AVG
PH
VH
HOLD
APH
APHA
AVH
AVHA
<Power Fault> & alarm
indicator are blinking
Pushing the keys of the control panel will cause the following actions:
enters the menu or save parameters
enters the next page
No action for 10 s forces the unit to leave the menu without saving of parameters.
46
info@Raytek-Direct.ca
Meaning
Average
Peak Hold
Valley Hold
Trigger set to HOLD function
Advanced Peak Hold
Advanced Peak Hold with Averaging
Advanced Valley Hold
Advanced Valley Hold with Averaging
Power via USB not sufficient to drive all analog outputs of
Communication box (DIN, 6TE), analog
Table 4: Symbols and Messages in the Display
Rev. F1 05/2013
Remark
Software controlled
Software controlled
Software controlled
Software controlled
Configuration of the box is possible
but outputs are set to disabled
