Outputs
6.5 Thermocouple Output TC
Comm Box:
Source:
Signal:
Terminal:
This output can be configured as thermocouple output type J, K, R, or S. For that output, you must
install a dedicated compensation cable. The output impedance is 20 Ω. The output is short circuit
resistant.
The outputs <OUT1> and <TC> are not available at the same time!
42
metal
object temperature
TCJ, TCK, TCR, or TCS
TC, GND
Rev. G Nov/2015
MI3
